No.6100-00
- Discontinued - Humidity Chamber
SK-120CHB-II
Calibration : Not available
JCSS Accredited Calibration : Not available
This product is discontinued.
Feature
■ Being simple and yet precise, this chamber generates stable humidity to calibrate meteorological instruments such as our thermohygrograph for weather measurement.
Description
■ Put our Assmann Psychrometer SK-RHG as a standard reference and a testee hydrometer, e.g. Sigma II Thermohygrograph together in the chamber to check the accuracy and modify the indication in a constant humidity ambient around 55%rh.
Specifications
| Cat. No. | 6100-00 |
| Product name | Humidity Chamber |
| Model name | SSK-120CHB-II |
| Generated humidity |
Approx. 55%rh May be stabilized at some value between 45 and 65%rh depending on desiccants and the ambient |
| Humidity stability in chamber |
±1% (ambient temperature change ±0.5°C/h) ±1.5% (ambient temperature change ±1.0°C/h) |
| Humidity distribution in chamber | ±0.5%rh |
| Operation ambient | 15 to 30°C with temperature change slower than 1°C/h, 30 to 80%rh without condensing |
| Materials | Stainless steel SUS430 |
| Dimensions | 600 (W) x 600 (H) x 580 (D) mm |
| Weight | 16 kg |
| Power | 100 VAC±10% |
| Standard accessories | Desiccant package 500 g x1, Spare fuse x1 |
