- Discontinued - Remote Sensing Dial Thermometer for Wall Mount, 0 to 500°C

Feature

■ A robust industrial temperature gauge to measure temperature of a distant place with liquid sensor.

■ This model SB-100S shares most specifications with LB-100S thermometer series; all stainless steel SUS304, dimensions of sensing stem 12 mm dia. x 100 mm, 1/2" PT screw. The unique characteristic for SB-100S, measuring range 0 to 500°C, is that it contains mercury in its sensing stem.

Description

■ Notice:

Order a temperature range which covers your target temperature with a safe margin. For example, order 0 to 150°C if the temperature is expected to be up to 100°C.

Order a protector pipe in addition in the following cases:

- The sensing stem receives pressure more than 5 kgf/cm²

- A target object is corrosive; however, there is a probability that the protector pipe made of stainless steel can not prevent corrosion, thus ask us for details

Ask us for details about make-to-order products, or if this product is located in a vibrating place.

■ Drawing

Specifications

Cat. No.	3400-50
Product name	Remote Sensing Dial Thermometer for Wall Mount, 0 to 500°C
Model name	SB-100S
Measuring range	0 to 500°C
Accuracy	±10°C
Minimum scale	10°C
Waterproofness	IPX1 drip-proof
Materials	Body: Stainless steel Window: Glass
Dimensions	Dial case/window: 110 mm/100 mm diameter Sensing stem: 12 mm dia. x 100 mm (L) Lead wire: 3 m (L)
Screw	1/2" PT, strength 5 kgf/cm2
